This application note describes a process for oncolytic adenovirus production, from upstream cell culture to downstream purification, using modern tools and technologies. Upstream virus production was performed in A549 cells using the single-use ReadyToProcess WAVE™ 25 rocking bioreactor system. Virus was released from the host cells by treatment with Tween™ 20 and clarified using ULTA™ filter capsules followed by concentration and buffer exchange using hollow fiber filters. Anion exchange (AEX) chromatography was used for virus capture and size exclusion chromatography (SEC) for polishing. The downstream process was optimized to meet regulatory demands on product purity and quality. Well-established analytical methods were used to ensure accurate monitoring of the processed material.
Oncolytic viruses constitute a new promising therapeutic approach for treatment of cancer. These viruses selectively replicate in tumor cells and effectively kill these cells without harming normal cells. Selectively engineered, the virus does not only destruct the target tumor cell, but also stimulate the host’s anti-tumor immune response.
Adenovirus is an extensively characterized and well-studied viral vector that infect both dividing and non-dividing cells without the risk of integration into the host genome. Also, generally causing a mild nature of disease, adenoviruses are considered as safe delivery vectors for gene therapy applications. Recently, oncolytic adenovirus has successfully been applied as cancer immunotherapies or tumor vaccines. As one of the most studied vectors for experimental and clinical use, adenovirus serotype 5 (AdV5) is a suitable system for development of a process for oncolytic adenovirus production.
Human lung carcinoma cells (A549) are commonly used for production of recombinant adenovirus for human gene therapy, including oncolytic adenovirus. A549 cells are traditionally propagated in adherent culture with serum-containing medium. As scaling up of anchorage-dependent cells can be a challenge, suspension cell cultures are therefore preferred as these are more easily scaled. However, adaptation of suspension cells can be time-consuming and difficult, and might affect virus titer negatively, making alternative solutions more feasible for laboratory- and clinical-scale production. One attractive alternative for scale-up using adherent cells is the use of microcarriers.
Previous work has demonstrated adenovirus production in HEK293 suspension cells using the ReadyToProcess WAVE 25 bioreactor system (1–4). In this work, performed by iBET, Oeiras, PT, anchorage-dependent A549 cells were grown in serumcontaining medium using HYPERFlask™ cell culture vessels, and thereafter in suspension for production of oncolytic adenovirus in serum-free medium using the ReadyToProcess WAVE 25 bioreactor system.
In the harvest step, 0.5% Tween 20 was used for cell lysis to release adenovirus from the host cell instead of the commonly used Triton™ X-100, now on the authorization list (Annex XIV) of registration, evaluation, authorization, and restriction of chemicals (REACH) (5). For downstream purification, normal flow filtration (NFF) was used for clarification and tangential flow filtration (TFF) was used for concentration and buffer exchange. Two AEX resins were evaluated for the capture step. Following a second concentration step, polishing was conducted by SEC before sterile filtration of the final bulk product. An overview of the process is given in Figure 1.
Materials and methods
Cell expansion and bioreactor culture
A549 cell line (ATCC) was routinely propagated in tissue culture flasks at an inoculum density of 3 × 103 cells/cm2 using Ham´s F12 medium, Kaighn´s modification supplemented with 10% fetal bovine serum (FBS). Prior bioreactor cultivation, adherent A549 cells were amplified in HYPERFlask vessels. At approximately 90% confluence, cells were harvested by trypsination and centrifuged at room temperature to remove serum-containing medium. Cells were resuspended in HyClone™ CDM4HEK293 medium supplemented with 4 mM L-glutamine for growth in suspension bioreactor culture using the ReadyToProcess WAVE 25 system equipped with a 10 L Cellbag™ culture vessel. Cells were inoculated at 0.5 x 106 cells/mL in a working volume of 5 L. Samples were taken every 24 h for determination of cell density and viability.
Virus propagation and harvest
The cells were infected with oncolytic AdV5 at a multiplicity of infection (MOI) of 10 at 72 h after inoculation. Cell lysis was performed 48 h post infection by the addition of Triton X-100 to a final concentration of 0.1% (evaluation experiments) or Tween 20 to a final concentration of 0.5% (scale-up experiments). Benzonase™ was added at 100 U/mL at the initiation of cell lysis for digestion of host cell DNA (hcDNA). Digestion was allowed to proceed for 4 h at 37°C and 16 rpm.
Clarification, concentration, and buffer exchange
Clarification of the harvest material was performed by NFF, using 47 cm2 ULTA filter discs (2 μm GF and 0.2 μm CG) for the trials in 1 L scale and ULTA Prime capsules (5 μm GF 6 inch and 0.2 μm CG 4 inch) for 5 L scale up. These clarifications were performed with fixed pressure of 0.2 bar for 2 μm GF and 0.1 bar for 0.2 μm CG. For the 5 L scaled-up culture, the clarification was performed with constant flow of 600 L/m2/h.
The clarified bulk was thereafter concentrated using hollow fibers with 26 and 50 cm2area for pore size trials NMWC Mr 300 000, Mr 500 000, and Mr 750 000 at a feed flow of 40 mL/min and a constant transmembrane pressure (TMP) of 1 bar. For the 5 L scaled-up culture, 290 cm2 hollow fiber filter with NMWC Mr 750 000 at a feed flow of 300 mL/min and a constant TMP of 1 bar. The bulk was concentrated 2 times and diafiltrated 4 times, with 50 mM HEPES, pH 6.5 + 150 mM NaCl.
The intermediate purification step was executed using 120 mL of Capto™ Q or Capto Q ImpRes resin packed in HiScale 50/20 columns. The column was packed according to manufacturer’s recommendation on compression factor and thereafter qualified by determination of height equivalent to the theoretical plate (HETP) and asymmetry. The column was equilibrated with 50 mM HEPES, pH 6.5 + 150 mM NaCl and loaded with 1.5 × 1011 virus particles (VP)/mL resin. The runs were performed at 300 cm/h. The column was washed with 2 column volumes (CV) of 50 mM HEPES, pH 6.5 + 150 mM NaCl. A one-step elution was performed using 50 mM HEPES, pH 6.5 + 1 M NaCl. The pooled fractions for each run were diluted 1:4 with 20 mM Tris, pH 8 +
25 mM NaCl.
Concentration and polishing
The semi-purified samples were concentrated 9 times using a 290 cm2 hollow fiber filter with a nominal molecular weight cut-off (NMWC) of Mr 300 000 (UFP-300-C-3X2MA) with a flow of 200 mL/min and a TMP of 1 bar. The samples were diafiltrated 2 times with 20 mM Tris, pH 8 + 25 mM NaCl. For evaluation of loading volumes, an XK16/20 column packed with 34.5 mL Sepharose 4 Fast Flow was used. Obtained samples were thereafter loaded onto 300 mL Sepharose 4 Fast Flow resin packed in an XK50/60 column pre-equilibrated with 20 mM Tris, pH 8 + 25 mM NaCl. The virus-containing fractions were collected, pooled, and formulated by the addition of a stock solution of 20 mM Tris-HCl, pH 8 + 25 mM NaCl + 25% glycerol to a final concentration of 2.5% of glycerol.
For the sterile filtration, an ULTA Prime CG disc was used. The membranes were pre-equilibrated with 20 mM Tris-HCl, 25 mM NaCl, 2.5% glycerol, pH 8. The filtration was performed at a flow of 600 L/m2/h.
Total protein quantification
Total protein concentration was determined by BCA protein assay kit (23225, Thermo Fisher).
Total DNA quantification
Total DNA was assessed using the Quant-iT™ Picogreen™ dsDNA Assay Kit (P7589, Invitrogen), according to the manufacturer ‘s instructions.
A549 host cell protein ELISA
A549 host cell protein (HCP) were measured using an ELISA method (F230, Cygnus Technologies).
To ensure that the endonuclease added in the process was removed, the Benzonase concentration in the final sample was measured using the Benzonase ELISA kit II (1016810001, Merck).
Infectious particle quantification
Oncolytic AdV5 infectious titer was determined by an end-point dilution method (TCID50). In brief, 100 μL A549 cells (0.5 × 106 cells/mL) were seeded in 96-well tissue culture plates and incubated overnight at 37°C in 5% CO2. The next day, the supernatant was replaced by serial dilutions (10-1 to 10-11) of virus. Cytopathic effect on cells was determined 10 days later using inverted microscope and the TCID50 titer determined using Spearman-Karber statistical method.
Viral genome particle quantification
Oncolytic AdV5 quantification of viral genome copies was determined by quantitative real-time polymerase chain reaction (qPCR). Before DNA extraction, samples were treated with 10 U DNAse for 30 min at 37°C. The reaction was stopped by addition of 8 mM EDTA and incubation at 75°C for 10 min. Viral copies were thereafter extracted using High Pure Viral Nucleic Acid Kit (11858874001, Roche). The viral genome copies were quantified by qPCR using the LightCycler™ 480 Probe Master (0470749001, Roche) and the LightCycler 480 instrument (Roche).
Results and discussion
After stepwise evaluation on individual process steps for oncolytic AdV5 production and purification, the complete process was performed. Adherent A549 cell expansion was conducted in HYPERFlask vessels using Ham´s F12 medium, Kaighn´s modification supplemented with 10% FBS. Harvested cells were centrifuged for removal of serum, resuspended in complete CDM4HEK293 medium, and inoculated (0.54 × 106 cells/mL) in the Cellbag culture vessel at 5 L working volume (Fig 2). Three days post inoculation, when grown to 0.8 × 106cells/mL in suspension, the cells were infected with oncolytic AdV5 at MOI 10. The culture was harvested by addition of Tween 20 to a concentration of 0.5% in 10 mM Tris, pH 8 to lyse the cells, 100 U/mL of Benzonase for DNA fragmentation, and incubated for 4 h at 37ºC. Volumetric productivities of infectious virus particles (IP) and viral genomes (VG) were assessed by TCID50 and determined to 1.17 × 1010 IP/mL and 1.12 × 1011 VG/mL, respectively (Fig 3). The VG/IP ratio after harvest was calculated to 9.5.
Clarification filters were evaluated in two steps, with initial trials performed with 1 L bioreactor harvest and scale-up with 5 L bioreactor harvest (Table 1). The two filters 5 μm GF followed by 0.2 μm SG filters were selected and resulted in removal of cell debris and initial reduction of proteins and DNA with high virus recovery, showing no significant reduction in total vp/mL. The turbidity level was also significantly reduced.
Ultrafiltration/diafiltration (UF/DF) was evaluated on hollow fiber filters with three different membrane NMWCs of Mr 300 000, 500 000, and 750 000 according to Table 2. Samples were concentrated 4 times and diafiltrated 5 times. Results suggest that DNA and protein removal in all the hollow fiber devices, converges to the same removal percentage (Fig 4). Moreover, it was also observed that at Mr 750 000, the maximum impurity removal was achieved earlier, which can be justified by the larger pore size that facilitates impurity permeation.
Total particle comparison between the different hollow fiber filters displayed highest recovery with Mr 500 000 and 750 000 (Fig 5). Considering impurity removal and virus recovery, the Mr 750 000 filter presented the best performance of the filters evaluated and was therefore selected for process evaluation.
Traditional intermediate purification protocols commonly use AEX chromatography. Two resins, Capto Q and Capto Q ImpRes, were evaluated. Capto Q ImpRes showed 3.6 times higher dynamic binding capacity (DBC) and higher virus recovery at similar impurity removal (Table 3). The higher DBC seen with the Capto Q ImpRes resin can be explained by the smaller bead size, offering a larger surface area for virus binding. Capto Q ImpRes was therefore selected for the capture step.
The removal of hcDNA is facilitated by fragmentation using nuclease treatment (Benzonase). Shorter DNA fragments will be removed in the permeate of the UF step, and remaining DNA is removed in the wash fractions of the AEX step, as shorter fragments bind less strong and elute at lower salt concentration than longer DNA fragments. Any remaining long DNA fragments after the nuclease treatment can be removed in the final SEC polishing step.
Sepharose Fast Flow 4 was used for the polishing step. Sepharose Fast Flow allows to inject between 0.1 to 0.3 CV of sample for optimal remaining impurity removal. Different ratios of sample volume (SV) to CV were evaluated for the polishing step (Fig 6).
As an alternative for the polishing step, Capto Core 700 with the advantage of a 100–300-fold higher load capacity can be used instead of SEC (6) provided that the majority of any longer DNA fragments has been removed in the prior steps. Longer DNA fragments may not be efficiently reduced by Capto Core 700 due to the cut-off of this resin.
Oncolytic adenovirus process runs
Two complete processes of 2 L oncolytic adenovirus production, from a 5 L bioreactor culture were used for process verification. First, the 2 L productions were harvested by adding Tween 20 to a concentration 0.5% (v/v), using a stock solution, containing 5% Tween 20 in 10 mM Tris, pH 8 and 100 U/mL of Benzonase, to the bulk previously diluted in 50 mL of medium and incubated for 4 h at 37ºC.
The downstream process steps were conducted as described in Table 4. Product recovery for all steps of the process was assessed by quantification of viral genomes (VG) by qPCR, and infectious particles (IP) by TCID50 assay. Removal of dsDNA, total protein, and HCP throughout the process was also evaluated, as was the residual Benzonase concentration in the final sample.
The VG and IP recoveries are listed in Table 5. The recovery of each step in the process will affect the overall process recovery and optimization of each step is therefore important. Average overall recovery was 52% and 61% for VG and IP, respectively.
However, overall recoveries varied, ranging from 34% to 70% in the two successful proof-of-concept runs. The lower recovery in the first run can be explained by the difference of almost 1 log in virus concentration throughout the process. This might indicate that the process favors higher virus concentrations (~ 1011).
Average impurity removal, total protein, dsDNA, and HCP for both runs are shown in Table 6. In the first run, more that 99% of all impurities were removed. As expected, DNA was the most difficult impurity to remove. In the second run, only 94.5% of the dsDNA was removed. This can be due to the presence of higher concentration of virus in the sample. As the virus can form virus-DNA complexes, the amount of Benzonase added in the beginning of the process might not have been enough to break such complexes and the DNA removal was thus less effective throughout the process. The VG/IP ratio was similar in the final sample as obtained after harvest, which suggests that the process steps did not affect infectivity of the virus negatively. The purity of the final samples meets the regulatory requirements (Table 7).
The described oncolytic AdV5 production process ranges from cell expansion to purified virus bulk product. Here, adherent A549 cells were amplified in serum-containing medium, after which virus was produced in suspension bioreactor cultures using serum-free medium in working volumes ranging from 1 to 5 L. CDM4HEK293 medium was selected to support A549 cell growth and productivity in suspension culture using the single-use ReadyToProcess WAVE 25 rocking bioreactor system. This system was used as it supports smooth rocking motion that lowers shear force for sensitive cells. The system is also favorable for its simplicity when performing laboratory-scale production cultivations.
Two complete downstream process runs, using Capto Q ImpRes for the capture step and Sepharose 4 Fast Flow for the polishing step, were executed, both runs confirming impurity removal of above 94% and virus recovery of up to 70%. It was shown that a higher virus particle concentration in the bulk after harvest favors process recovery. The downstream process provided high virus purity, with impurity concentrations below target in the final
sample for both processes.
We thank iBET, Oeiras, Portugal for producing and sharing data and for good collaboration.
1. Application note: Evaluation of HEK293 cell growth and adenovirus productivity in HyClone CDM4HEK293 medium. GE Healthcare, 29264715, Edition AA (2017).
2. Application note: Adenovirus production in single-use Xcellerex™ XDR-10 bioreactor system. GE Healthcare, KA874021017AN (2017).
3. Application note: Adenovirus production in single-use ReadyToProcess WAVE 25 bioreactor system. GE Healthcare, KA879160418AN (2018).
4. Application note: Scalable process for adenovirus production. GE Healthcare, KA877080618AN (2018).
5. Application note: Optimization of midstream cell lysis and virus filtration steps in an adenovirus purification process, GE Healthcare, KA875220218AN (2018).
6. Application note: Scalable process for adenovirus production. GE Healthcare, KA877080618AN (2018).
